Hayward Face Plate With Threads | SPX1411B

Hayward Face Plate With Threads | SPX1411B

Original price was: $13.35.Current price is: $8.55.

77 in stock

SKU: SPX1411B Category:

Description

HAYWARD | FACE PLATE WITH THREADS | SPX1411B



THIS IS THE 4 HOLE OLD STYLE FACEPLATE USED ON THE HAYWARD SP-1411 VINYL LINER INLET FITTING THIS OLDER VERSION HAS 1-1/2″ FEMALE THREADS ON THE INSIDE. THIS IS WHERE THE EYEBALL SCREWS IN MATERIAL: WHITE ABS PLASTIC THIS IS ROUND WITH 4 EVENLY SPACED HOLES ON THE FRONT AND A COMPLETELY FLAT BACK WITH 2 SMALL PARTIAL HOLES. THE 4 SCREW HOLES ARE 1/4″ AND HAVE COUNTERSINKS THAT ARE 15/32″ DIAMETER THE 4 SCREW HOLES ARE 2-7/16″ APART ON THE CENTERLINE FROM ONE HOLE TO THE OPPOSITE HOLE OUTSIDE DIAMETER: 3-9/16″ (A) INSIDE DIAMETER: 1-3/4″ (B) THICKNESS: 9/32″
