DISPLAY BOARD AND CABLE EXT | HDXFDSPB0001

Description

DISPLAY BOARD AND CABLE EXT | HDXFDSPB0001

Hayward Display Board and Cable Extension (HDXFDSPB0001) Used in Hayward pool and spa control systems, for managing and displaying heater settings and diagnostics in models like the HDF400. It provides a user interface for operating the system and connects to other electronic components via its cable extension.

• User Interface for Controls:
  The display board shows key operational data, such as temperature settings, status indicators, error codes, and other information. Users interact with the system through buttons or a digital touchscreen.
• Cable Extension for Connectivity:
  The cable extension enables the connection of the display board
  to the heaters main control board. This transmits data between the control system and the display, enabling real-time status updates and command inputs.
• Error and Diagnostic Display:
  If the system encounters issues, the display provides error codes or alerts, helping troubleshoot problems and guiding maintenance or repairs.
