Century Pool Pump Motor 2HP 1 Phase 60Hz 230V Y56Y | B985

Description

Century B985 2-Speed Pool Pump Motor 2.0/0.33 HP, 230V, 56Y Square Flange

The Century B985 is a 2-speed replacement pool pump motor designed for compatible pool and spa pump applications that use a 56Y square flange frame. This motor operates on 230 volts and provides high-speed and low-speed performance for circulation systems that need both stronger flow and lower-speed energy-saving operation.

Features

• Genuine Century replacement pool pump motor
• Part number: B985
• 2-speed motor
• 2.0 / 0.33 HP
• 230V, single phase, 60Hz
• 56Y square flange frame
• 3450 / 1725 RPM
• Service factor: 1.10
• Total horsepower: 2.2 THP
• Approximate amps: 10.0 / 3.5
• 5/8 inch threaded 303 stainless steel shaft
• Open dripproof enclosure
• High-efficiency design
• Automatic thermal overload protection
• Counterclockwise rotation facing pump end

Applications

This motor is commonly used as a replacement for compatible pool and spa pumps requiring a 2-speed, 230V motor with a 56Y square flange frame and threaded shaft. It is often used on compatible Sta-Rite Dyna-Pro, Dyna-Jet, Max-E-Glas, Dura-Glas, and Max-E-Pro style pump applications where the original motor matches the frame style, voltage, shaft configuration, and rotation requirements.

Important Notes

• Verify frame type, voltage, horsepower, shaft size, and rotation before ordering
• This is a 230V motor only
• Designed for square flange pump applications
• Hi/low switch may be sold separately depending on configuration
• Motor seal and gaskets are typically sold separately
• Professional installation is recommended

Related Products

• Century Pool Pump Motor Square Flange 2HP 48Y | USQ1202
• Century Pool Pump Motor Square Flange 1.5HP 48Y | USQ1152
• Shop Pool Pump Motors

Maintenance Tips

• Keep the motor area clean and well ventilated to help prevent overheating
• Inspect the shaft seal area regularly for leaks that could damage the motor bearings
• Make sure wiring and speed selection are configured correctly before startup
• Replace worn seals, capacitors, or bearings promptly to help extend motor life
